Fluke PM2813 - Page 33

Installation Instructions 3 - 5
Local sensin
g
The SENSE switch is in ’LOCAL’ position if S1 is ’closed’.
CAUTION: Do not connect a load to the sense terminals +S and -S, because the
maximum current throu
g
h the switch is limited to 4 A. Currents
exceedin
g
this limit will dama
g
e the switch.
Also make sure that the sense wires (used for remote sensin
g
) are
disconnected from the sense terminals to prevent current throu
g
h the
sense switches.
Remote sensin
g
The SENSE switch is in ’REMOTE’ position if S1 is ’open’. The sense terminals
must be connected to the load.
Load
+S
+V
-V
-S
S1
S1
Load
+S
+V
-V
-S
S1
S1
