DC Inverter U-match Series Duct Type Unit
43
①
. Power cord 3×6.0mm²
②. Power cord 3×1.0mm²
③. Communication Cords 2×0.75mm²
④. Communication Cords 2×0.75mm²
Three-phase unit: 10.0KW, 12.5KW, 14.0KW
Power:380-415V 3N ~ 50Hz/60Hz
Outdoor Unit
Indoor Unit
Wired
Controller
Power:220-240V~ 50Hz/208-230V ~60Hz
L2
L1 L3
N
2
1
2
1
H1
H2
breaker
breaker
Power:380-415V 3N ~ 50Hz/60Hz
Outdoor Unit
Indoor Unit
Wired
Controller
Power:220-240V~50Hz/208-230V~60Hz
breaker
L1
L2
L3
N
PE
①
. Power cord 5×1.5mm²
②. Power cord 3×1.0mm²
③. Communication Cords 2×0.75mm²
④
. Communication Cords 2×0.75mm²
14.0KW
10.0KW
12.5KW
14.0KW
