Fluval FX6 User Manual

Pump Care: Impeller Maintenance
WARNING: ALWAYS DISCONNECT ALL APPLIANCES IN THE AQUARIUM FROM ELECTRICITY SUPPLY
BEFORE PLACING HANDS IN THE WATER, BEFORE PUTTING ON OR TAKING OFF PARTS, AND
WHENEVER THE FILTER EQUIPMENT IS BEING INSTALLED, MAINTAINED OR HANDLED.
The impeller well has an effective self-cleaning feature. However it is recommended that you remove the
motor and inspect the impeller as part of your routine maintenance. Keeping the impeller clean lengthens
its life and the life of the motor. Prior to performing pump care the FX6 Filter must be completely emptied of
water, media baskets, and media.
1. Empty the filter canister by following the steps outlined
in the Media Care Section. Move unit to appropriate work
space.
2. Remove all media baskets with media from the filter
canister. Empty the canister completely in a sink or basin.
3. To remove the pump unit:
a. Place the filter unit upside down on a secure work
area so that the pump screws and screw seats are
visible. Remember that the output tube protrudes slightly
from the top rim of the canister. Be sure not to bend or
damage the tube while it is upside down.
b. Unscrew the 4 fixing screws using a Phillips screw-
driver (cross headed). Screws are located around the
motor housing.
c. Remove the impeller assembly by grasping its flange
(black disc).
4. Clean the impeller and the impeller well thoroughly by
rinsing with clear running water.
MAINTENANCE PUMP CARE
b
c
EN-22

Fluval FX6 Specifications

General

Internal	No
Easy to use	Yes
Water compatibility	Freshwater, Sea water
Aquarium capacity (max)	1500 L
Number of filter chambers	6
Country of origin	Italy
AC input voltage	120 - 240 V
AC input frequency	50/60 Hz
Warranty period	3 year(s)

Weight and Dimensions

Width	400 mm
Height	530 mm
