FLX BLADE 2.0 - Components; Components Overview

BLADE 2.0 | USER MANUAL | 4
COMPONENTS
HEADSET
HEAD TUBE
TOP TUBE
DOWN TUBE
FRONT FORK
PAGE 12
SEAT TUBE
SEAT STAY
DROPOUT
HANGER
CHAIN STAY
MOTOR BRACKET
THRU-AXLE
BELT FRAME SPLIT
COCKPIT
SADDLE
SEAT POST
SEAT CLAMP
DISPLAY PAGE 13
STEM
HANDLEBARS
SPEED SHIFTER
FRONT BRAKE LEVER
REAR BRAKE LEVER
THUMB PAD REMOTE
THUMB THROTTLE
CHASSIS
DRIVETRAIN
BATTERY
PAGE 16
MOTOR
PAGE 15
INTERNAL GEAR HUB
PAGE 17
REAR COG
BELT (CHAIN)RING
SPIDER
CRANK BOLT
CARBON BELT
PAGE 18
CRANK
SPEED SENSOR
Familiarize yourself with the components of your model. This are
technical terminolagy used at the FLX engineering department. `
BRAKE ROTOR
BRAKE CALIPER
PAGE 14
WHEELS
TIRE PAGE 20
REFLECTOR
FRONT HUB
RIM PAGE 19
SPOKES
WHEELS
RACK
REAR FENDER
FRONT FENDER
Valve
