FLX BLADE 2.0 - Geometry; Blade 2.0 - Size L Geometry; Other Dimensions

BLADE 2.0 | USER MANUAL | 6
GEOMETRY
Seat Tube Length
Seat Tube Angle
Head Tube Length
Head Tube Angle
Stack
Effective Top Tube
Reach
Standover Height
Wheelbase
Chainstay Length
Bottom Bracket Drop
Bottom Bracket Height
OTHER DIMENSIONS
Fork Height
Fork Rake
Seat Post Insert
Seat post diameter
Headset spacer
Stem length
Stem angle
Handlebar Diameter
Handlebar Width
Cranklength
Wheel size
Wheel radius
A.
B.
C.
D.
E.
F.
G.
H.
I.
J.
K.
L.
17.7 Inches (450 mm)
73.5°
5 Inches (130 mm)
69°
26.5 Inches (670 mm)
25 1/8 Inches (638mm)
17 1/3 Inches (440 mm)
28 1/3 Inches (720 mm)
47 Inches (1190 mm)
18 Inches (460 mm)
2 Inches (47 mm)
12 Inches (311 mm)
567.1 mm
51 mm
min 100 mm - max 200 mm
31.6 mm
10 mm
50 mm
0°
31.8 mm
780 mm
170 mm
27.5*2.6” or 29*2.1”
365 mm
BLADE 2.0 - SIZE L
