11
4. Operation Instructions
After setting up, follow the instructions below to operate the system.
4.1 Power On
Follow the steps below to turn on the system:
1. Check the system and make sure that:
• The batteries are fully charged and installed properly.
• The receiver is off and correctly installed.
2. Toggle the power switch to its upward position.
3. Connect the receiver power supply to the
BAT
port on the receiver.
The system is now powered on.
4.2 Switching Between AFHDS 2A and AFHDS
To switch between AFHDS 2A and AFHDS , hold both stick at the bottom left corner and turn on the
transmitters power at the same time. Wait for 1 second then turn the power off again to save the new
setting.
AFHDS : The LED will light up for one second.
AFHDS 2A : The LED will light up for one second followed by a sound.
RF Protocol Receiver
AFHDS GR3F, GR3E, R6B, R9B
AFHDS 2A A3, A6, iA4B, iA6, iA6B, iA10,
iA10B
