13
4. Switch the gimbals to the opposite side. Make sure the gimbals have been rotated 180 degrees so
that the wires are facing towards the middle of the system.
5. Move hat of the S16 connector so that one side is on the L or R pin, L for when the self centring stick
is on the left side and R for when its on the right.
Left Seat
Right Seat
S16
6. Reconnect the back's cables, reattach the back and tighten the screws.
4.6 Power Off
Follow the steps below to turn off the system:
1. Disconnect the receiver power.
2. Toggle the transmitter's power switch to its low position.
Danger
• Make sure to disconnect the receiver power before turning off the transmitter.
Failure to do so may lead to damage or serious injury.
