12
Step 5: Install the front fender
A. Loosen the eye bolt at the top of the fork by hand. Remove eye bolt and washer
and set aside.
B. Using the provided 4mm allen wrench, remove the screws on either side of the
fork. Set aside.
C. Position the fender inside the fork, lining up the bracket to the threaded hole in
the top of the fork. Reinstall the eye bolt and washer. Tighten by hand.
D. Align the fender frame with the threaded holes in the fork.
Re-install the screws and washers using the provided 4mm allen wrench.
A
D
B
C
