FLYGT 4660 - Materials; Weights

9
Weights
Max. weight of mixer and PP-pump irrespective of
material, including lifting device but without motor
cable is:
4630 Mixer without jet ring 55 kg ( 121 lb)
Mixer with jet ring 60 kg ( 132 lb)
Flange mounted mixer
1)
70 kg ( 154 lb)
Cooling jacket
2)
3.3 kg ( 7.3 lb)
PP-pump 77 kg ( 170 lb)
4640 Mixer without jet ring 60 kg ( 132 lb)
Mixer with jet ring 70 kg ( 154 lb)
Flange mounted mixer
1)
75 kg ( 165 lb)
Cooling jacket
2)
3.3 kg ( 7.3 lb)
PP-pump 85 kg ( 187 lb)
4650 Mixer without jet ring 150 kg ( 330 lb)
Mixer with jet ring 175 kg ( 386 lb)
Flange mounted mixer
1)
150 kg ( 331 lb)
Cooling jacket
2)
7.5 kg (16.5 lb)
PP-pump 204 kg ( 450 lb)
4660 Mixer without jet ring 190 kg ( 419 lb)
Mixer with jet ring 220 kg ( 485 lb)
Flange mounted mixer
1)
190 kg ( 419 lb)
Cooling jacket
2)
7.5 kg (16.5 lb)
PP-pump 251 kg ( 553 lb)
4670 Mixer without jet ring 285 kg ( 628 lb)
Mixer with jet ring 350 kg ( 772 lb)
Flange mounted mixer
1)
300 kg ( 661 lb)
Cooling jacket
2)
11 kg ( 24 lb)
PP-pump 410 kg ( 904 lb)
4680 Mixer without jet ring 405 kg ( 893 lb)
Mixer with jet ring 470 kg (1036 lb)
Flange mounted mixer
1)
415 kg ( 915 lb)
Cooling jacket
2)
11 kg ( 24 lb)
PP-pump 533 kg (1175 lb)
1)
without jet ring and lifting device
2)
not including tubes and couplings
Materials
Denomination Materials Flygt No EN ASTM
Propeller Stainless 0344. 1.4432 316L
steel 2343.02
or
Alloyed white 0314. GLJ 250 A 532
iron (L102) 0466.20 (ALLOYIIIA)
Major castings
1
Cast iron 0314. — A48
0125.00 No 35B
Shaft
1
Stainless 0344. 1.4021 420
steel 2303.05
Oil housing, Vinylester 0544. ——
Propeller cover SMC CR30 9585.70
Bearing casing Aluminiun 0404. DIN B85A413.0
4630 and 4640 4263.10 1725/68 A1413.0
GD-AISi12
BS
1490:70
Coupling, Cooling Stainless 0344. 1.4432 316L
jacket, Tubes steel 2343.02
O-rings, Gasket, Nitrile 0516. ——
Cable entry, rubber (NBR) 2637.04
Seal sleeve, 70°IRH (black)
or
Fluorinated- 0516. ——
rubber (FPM) 2677.32
70°IRH (green or black with a violet dot)
Unic for mixer of General Purpose Stainless Steel (GP) ASTM 304
Jet ring, Fixing Stainless 0344. 1.4301 304
plate, Inlet cone, steel 2333.02
Lifting clamp
Lifting device, Stainless 0344. 1.4432 316L
Support, Seal steel 2343.02
holder, Motor casing,
Guiding rollers, Screws,
Unic for mixer of High Grade Stainless Steel (HP) ASTM 316
Jet ring, Fixing Stainless 0344. 1.4432 316L
plate, Inlet cone, steel 2343.02
Lifting device,
Support, Seal holder, Motor casing, Guiding rollers, Screws,
Unic for mixer of Proacid 254 (PA) ASTM S31254
Jet ring, Fixing Proacid 0344. 1.4547 UNS
plate
2
, Inlet cone, 254 2378.02 S31254
Lifting device,
Support, Seal holder, Motor casing, Guiding rollers, Screws,
Mechanical face seals plug-in type:
Size Inner seals Outer seals O-rings
4630, 4640 CSb/Al
2
O
3
WCCR/Al
2
O
3
NBR
WCCR/Al
2
O
3
WCCR/WCCR FPM
WCCR/Al
2
O
3
RSiC/RSiC FPM
4650 - 4680 Csb/WCCR WCCR/WCCR NBR
WCCR/WCCR WCCR/WCCR FPM
WCCR/WCCR RSiC/RSiC FPM
Csb = Carbon
AL
2
O
3
= Aluminium oxid
WCCR = Corrosion resistant cemented carbide
RSiC = Silicon carbide
1)
Not exposed,
2)
Not for flange mounted mixer
