7.2. Cables
1. Take the Big box/rigging, Big box/trapeze packs and Pack rigging.
2. Lay the mast on the boat, spreaders down, and with the top of the mast to the rear of the
boat.
3. Arrange the cables with regard to the mast: a shroud Str M3503 on each side and the Str
M3405 forestay in the middle.
4. Repeat the above procedure for the trapezes M2707 and M2708.
5. Fix the trapezes on the side of the small loop at the shrouds eyelet with a lark’s head as
shown below.
6. Attach the cables to the mast using the caping shackle of the mast. Insert the washers to
remove the loose.
