MPU Dispatch Check Procedure
_____________________________________________________________________
____________________________________________________________________
Page 10 of 28 PRD-0000022543 Rev .00D
MNKS008 0.0 (4/08)
3.2. Results/Output Registers
The following registers are the results registers of the MPU Series B.
They are all 32-bit float values. They are updated on the completion of
every measurement cycle.
Object
number
ModBus
Address
Description Unit
0 0 Log count
*1
-
1 2 Alarm Status
*2
-
2 4 Flow Velocity m/s
3 6 Velocity of Sound m/s
4 8 Actual Volum Flowrate m
3
/h
5 10 Accumulated Volume Forward m
3
6 12 Accumulated Volume Reverse m
3
7 14 Accumulated error volume foward m
3
8 16 Accumulated error volume reverse m
3
9 18 Accumulated time
*3
sec
10 20 Volume Increment
*4
m
3
11 22 Increment Time Duration
*5
sec
12 24 Used Line Pressure barA
13 26 Used Line Temperature Celsius
14 28 Measured Flow Velocity path 1 m/s
15 30 Measured Flow Velocity path 2 m/s
16 32 Measured Flow Velocity path 3 m/s
17 34 Measured Flow Velocity path 4 m/s
18 36 Measured Flow Velocity path 5 m/s
19 38 Measured Flow Velocity path 6 m/s
20 40 Measured Velocity of Sound path 1 m/s
21 42 Measured Velocity of Sound path 2 m/s
22 44 Measured Velocity of Sound path 3 m/s
23 46 Measured Velocity of Sound path 4 m/s
24 48 Measured Velocity of Sound path 5 m/s
25 50 Measured Velocity of Sound path 6 m/s
26 52 Percentage Of Signals Used Transducer 1A %
27 54 Percentage Of Bursts Used Transducer 2A %
28 56 Percentage Of Bursts Used Transducer 3A %
29 58 Percentage Of Bursts Used Transducer 4A %
30 60 Percentage Of Bursts Used Transducer 5A %
31 62 Percentage Of Bursts Used Transducer 6A %
32 64 Percentage Of Bursts Used Transducer 6B %
33 66 Percentage Of Bursts Used Transducer 5B %
34 68 Percentage Of Bursts Used Transducer 4B %
35 70 Percentage Of Bursts Used Transducer 3B %
36 72 Percentage Of Bursts Used Transducer 2B %
