www.fmiproducts.com
56131J 3
Models (V)DVF36TPNA/TPNPA series are
three-sided direct-vent gas replaces and
models (V)DVF36TSTA/TSTPA are two-sided
direct-vent gas replace heaters with sealed
combustion chambers.
Models (V)DVF36TPNEA/TPNPEA and (V)
DVF36STEA/TSTPEA use a direct spark
ignition with a 24 VAC control module. All
models have HI/LO valve that controls the
ame height. These units can be equipped
with louvers for circulating or with panels for
noncirculating operation.
Fan Kit model DVFFBK are available for these
units as an option. If you are uncertain as to
what gas your unit is equipped for, please
check the rating plate located in the interior
of the appliance opening or consult your local
FMI PRODUCTS, LLC distributor.
Early signs
of carbon monoxide poisoning resemble the
u, with headaches, dizziness or nausea. If
you have these signs, the replace may not
be working properly. Get fresh air at once!
Have replace serviced. Some people are
more affected by carbon monoxide than oth-
ers. These include pregnant women, people
with heart or lung disease or anemia, those
under the inuence of alcohol and those at
high altitudes.
Natural and
propane/LP gas are odorless. An odor-making
agent is added to the gas. The odor helps you
detect a gas leak. However, the odor added to
the gas can fade. Gas may be present even
though no odor exists.
Make certain you read and understand all
warnings. Keep this manual for reference. It
is your guide to safe and proper operation of
this replace.
-
Before beginning the installation of replace,
read these instructions through completely.
• This FMI PRODUCTS, LLC replace and
its components are safe when installed
according to this installation manual.
Unless you use FMI PRODUCTS, LLC
components, which have been designed
and tested for the replace system, you
may cause a re hazard.
• The FMI PRODUCTS, LLC warranty will
be voided by and FMI PRODUCTS, LLC
disclaims any responsibility for the follow-
ing actions:
a. Modification of the fireplace, com-
ponents, doors, air inlet system and
damper control.
b. Use of any component part not manu-
factured or approved by FMI PROD-
UCTS, LLC in combination with a FMI
PRODUCTS, LLC replace system.
c) Installation and/or operation in a
manner other than instructed in this
manual.
d) Burning of anything other than the type
of gas approved for use in this gas
appliance.
This appliance, when installed, must be
electrically grounded in accordance with lo-
cal codes, or in the absence of local codes,
with the National Electrical Code, ANSI/
NFPA 70.
The installation must conform to local codes,
or in the absence of local codes, with the
National Fuel Gas Code ANSI Z223.1. This
appliance complies with ANSI Z21.50.
Proper installation is the most important step
in ensuring safe and continuous operation
of the replace. Consult the local building
codes as to the particular requirements
concerned with the installation of all factory
built replaces.
This replace must be installed by a qualied
(certied or licensed) service person. It has
a sealed gas combustion chamber that uses
a millivolt gas control valve with a millivolt
ignition system.
SAFETy
Continued
To Next Page
