Putting into operation and indications
Two operating modes are supported:
Router: The unit serves as broadband router
2. PPPoE: The unit serves as modem with PPPoE interface
Required software drivers:
In the operating mode PPPoE, a PPPoE driver has to be installed and activated on the PC
which is connected to the
Microsoft Windows Vista as soon as Windows 7 have included a PPPoE driver. No more
The PPPoE driver for other Windows versions can be downloaded e.g. on the web-
In the operating mode router, only the current Ethernet and network drivers (TCP / IP) are
required on the connected PC. The
ly the requested PPP connection to the provider with the dial-up dates.
After inserting the SIM card and correct cabling of the
following status indications should be visible at the front of the router
external local supply voltage
Continuous light with short interruptions: Offline
Blinking (0.2 Hz): Bootloader
Continuous light: Offline, not registered on the
Blinking (0,2 s on; 2 s off): Online
Blinking ((0,1 s on; 0,2 s off): Update discontinued
Display I/O ports activity
For the configuration of the
a web interface is available,
which can be controlled via a PC which is connected with a LAN cable.
The default IP address of the
the network mask 255.255.255.0. The PC which is used for the configuration has to be
configured with “get network address automatically” (DHCP client).
