FMN alpha LTE HS - Quick Start; Configuration

14
15
For safety reasons, you should use HTTPS for the communication with the web
interface since the data is transmitted encoded this way.
The web interface serves for the configuration, the control and the update of the
alpha
LTE/UMTS 4/EDGE HS
.
For access to the web interface, all current browsers in their latest version are suitable.
The web interface is accessible in the standard configuration over
HTTP or HTTPS on the
IP address 192.168.192.168:
(
https://192.168.192.168
or
http://192.168.192.168
).
I
n delivery state the
alpha LTE/UMTS 4/EDGE HS
isn’t protected by a password. The
username is
user
.
In addition to the access via web interface it is also possible to make changes on the
device per ssh, scp or USB console.
Please note:
Keep in mind that the configuration of the LAN interfaces is done that way that you
can always access the
alpha LTE/UMTS 4/EDGE HS
over these interfaces.
Quick start
Insert your SIM card. In menu bar WAN settings you can choose the WAN mode (router or
modem). If your SIM card is protected by a PIN unlock your SIM card by entering the cor-
rect PIN now and with an instant click to „Save settings“ at the end of the menu bar. After
successful unlocking the SIM card, you can indicate access data automatically.
Compare the automatically generated proposals with the data supplied by your provider.
If necessary make manual adjustments to APN, Authentication settings, IP settings and
DNS settings. Confirm your settings with „Save settings“.
The
alpha LTE/UMTS 4/EDGE HS
independently generate a connection depending on
the operation mode (WAN mode) and get an IP address from provider (router) or it is
waiting for incoming PPPoE connections by connected devices.
In the menu bar under state it‘s possible to check your
alpha LTE/UMTS 4/EDGE HS
net-
work status. In the section network interfaces you can check if your device has obtained
an IP address (wwan 0) by your provider. You can see in operation mode modem at the
PPPoE state, if clients are connected. If a client is connected, the MAC address is display-
ed here.
Configuration
The current (set in the web interface) configuration can either be accepted directly, be
saved on the
alpha LTE/UMTS 4/EDGE HS
or in a file.
The configuration can be reset to different states. Apart from the reset to the last saved
configuration, all other activities will lead to the overwriting of the saved configuration.
The configuration can be loaded from the
alpha LTE/UMTS 4/EDGE HS
or over a file
upload.
For applying the settings of a configuration, it has to be saved and the unit has to be re-
booted.
