Technical data of the alpha LTE/UMTS 4/EDGE HS
l
Dimensions (W x D x H):
approx. (49 x 146 x 105) mm (with DIN rail
holder)
l
Protection class:
IP 20
l
Weight:
0,6 kg
l
Operating voltage:
10 ... 60 VDC
l
Maximum power consumption:
8 W at 12 V
l
Average power consumption:
4 W at 12 V
l
Network connection:
RJ45 sockets (standard Ethernet,
10/100 Mbps)
l
Main antenna connection:
SMA socket
l
AUX antenna connection
*)
:
SMA socket
l
Connection for operating voltage:
2 pole screw terminal
l
I/O ports:
8 pole screw terminal
l
USB interface:
1x host; 1x device
l
Operating temperature:
alpha LTE HS
:
-25 °C .... +50 °C
alpha UMTS 4 HS
:
-25 °C .... +60 °C
alpha EDGE HS
:
-40 °C .... +70 °C
Bit rates
alpha LTE HS:
l
GPRS/EDGE Class B, Multislot Class 10: max. 236 kbps DL and UL
l
UMTS: max. 384 kbps DL and UL
l
HSPA: max. 42,2 Mbps DL; 5,7 Mbps UL
l
LTE: max. 100 Mbps DL; 50 Mbps UL
alpha UMTS 4 HS:
l
GPRS/EDGE Class B, Multislot Class 10: max. 236 kbps
DL and UL
l
UMTS: max. 384 kbps
DL and UL
l
HSPA: max. 21,1 Mbps DL; 5,7 Mbps UL
alpha EDGE HS:
l
GPRS/EDGE Class B, Multislot Class 10: max. 236 kbps DL and UL
Frequencies in MHz:
alpha LTE HS:
l
LTE (800, 900, 1800, 2100, 2600)
l
UMTS (800, 2100)
l
GSM (900, 1800, 1900)
alpha UMTS 4 HS:
l
UMTS (800, 850, 900, 1900, 2100)
l
GSM (850, 900, 1800, 1900)
alpha EDGE HS:
l
GSM (850, 900, 1800, 1900)
*)
with deactivated GPS function an additional antenna can be connected on the
AUX antenna connection
