Model assembly
EN
Rear fuselage installation
HKM 3.0*10
1.Thread the extension wire through the
front fuselage trough, align and install the rear fuselage
to the rear of the front fuselage in the corre sponding slot
as shown.
2. Use the included screws （HKM3.0*10mm
x 2） to secure the rear fuselage vertically into place.
3.Install the clevis as shown.
4.With the servo centered, install and adjust the pushrod and clevises. Connect the linkage rod to the rudder regulator.
