Optional float installation
10
EN
Model assembly
1. Install the struts to both sides of the float. The front strut is
longer with 422mm length, the rear strut is shorter with 412mm
length. Wrong installation will cause difficulty landing and taking
off.
2.Install the float strut to the float with 8 screws as picture shows.
