Linkage rod installation
9
EN
Model assembly
2. Install the aerodynamic fairing for the mechanism to the top of
the fuselage and secure with two screws.
1.With the servo centered, install and adjust the pushrod and
clevises. Connect the clevis to the outermost hole on the control
horn.
