Landing gear set installation
Main wing installation
4
Model assembly
EN
1.Attach the landing gear set to the landing gear slot on the
underside of the fuselage. The five screws are installed as
shown .
1.Slide the wing spar into the fuselage then install both wings
over the wing spar and into the fuselage pass-through of the
fuselage.
NOTE: The connectors on both the wing and fuselage should be
firmly and precisely attached.
