Horizontal stabilizer installation
5
EN
Model assembly
HKM3.0*26mm
1. Slide the horizontal stabilizer spar into the pass through at the
rear of the aircraft.
2. Install the 2 piece (left and right) horizontal stabilizer as shown.
Ensure the control horn faces down.
2.Install the 2 wing struts on the fuselage mount using 2 R-clips.
3. Secure the wing structure onto the fuselage using 4 screws
as shown. Ensure that these screws are securely tightened.
