Installation of the vortex generators
Installation of other scale components
7
EN
Model assembly
1. Carefully apply CA to the indentations located on the leading
edge of the wings.
2. Carefully slide the vortex generators onto the indentations as
shown.
1. Carefully adhere the pitot tube to the leading edge of the wing
as shown.
2. Carefully apply CA to the indentations as shown.
3. Carefully slide the vortex generators onto the indentations.
