Model assembly
Wing installation
2.With the elevator servo at its neutral position, con-
nect the pushrod to the elevator and secure using a
hex key.
1.Rotate the threaded end of the spar into the fuse-
lage in the direction as shown, then use the included
metal key to tighten.
2.Slide the wing halves onto the fuselage until an
audible “Click” is heard.
NOTE: Check that the connectors have been
securely fastened onto the fuselage.
