FMS J-11 - Page 5

5
Model assembly
EN
3*4mm
Linkage rod installation
Install the left and right horizontal tails to the fixed
shafts as shown.
5. Install the fixed shaft sleeves, and secure the
horizontal tails with the included set screws.
1.Make sure the servos are in the neutral position.
Install the linkage rod to elevator servo arm.
