7.Install the braces that hold the horizontal stabilizer in place. (fig. 12-13)
9.Please secure the pushrod to the ball link while ensuring that the elevator surface is level with the
rest of the horizontal stabilizer; if not, please adjust the length of the linkage accordingly. (fig. 15)
8.Secure the horizontal stabilizer by attaching PA2.0x12 screws to the top of the horizontal stabilizer.
(fig.14)
10.Repeat step 9 for the rudder push rod and control horn. (fig. 16)
