A: 机身
B: 主翼
C: 平尾
D: 垂尾
G:碳纤管
H:桨
I: 桨罩组
A.
C.
H.
J.
E.
F.
I.
G.
D.
B.
E: 起落架组
F: 翼刀
J: 连接杆和螺丝
(7-HKM3.0*26) (4-HKM3.0*16)
(1-HKM3.0*20) (1-HKM3.0*40)
Einleitung
产品组成
产品特点
翼展: 1400mm (55.1in)
机身长: 1490mm (58.66in)
飞行重量: 约 2600g
电机: 无刷4258-KV550
翼载荷: 62.9 g/dm²(0.14oz/in²)
翼面积: 40.2 dm²(623.1 sp.in)
电调: 70A
舵机: 30克 x 4
产品参数
MSW Votec 322 是瑞士一款基于 Rihn DR-107 One 设计的串列
双座下单翼特技机，由 MSW 航空建造，专供民间飞行爱好者。
FMS 很荣幸给大家带来这款高复原度的 70mm 涵道 F/A-18F 超
级大黄蜂。
你没看错，继 MXS V2 之后，FMS 再次推出一款性能更加强大
的 3D 特技机！
FMS Votec322 机身采用流线型设计，像真的汉密尔顿涂装，高
度还原真机风貌；机翼采用中空工艺，减轻飞机重量，进一步
提高飞机性能；整架飞机大量使用碳纤加强杆，保证机体强度
可以承受暴力飞行；高扭力空心杯设计的 30g 数码金属舵机，
金属球头连接杆，实现 3D 精细控制，为蛇滚和吊机提供足够的
舵面控制角度和力度；翼尖小翼的设计优化气流导向，大大提
升低速操控性。此外，FMS Votec322 依旧延续 FMS 快拆快装
设计思路，只需十数颗螺丝，即可完成整架飞机的组装和拆卸
工作。值得一提的是，FMS首次使用木桨，高效率高强度的木
桨最大限度地减轻震动对飞行性能的影响。
在结构安装上，毒蛇延续了FMS一贯的设计风格，采用快拆快
装结构，舵角的球头连接设计，使飞行远离虚位，飞行动作更
精准。
如果 MXS V2 曾经让你欲罢不能，千万不要错过这款性能更加强
大的 FMS Votec322 ！
在组装产品之前，请仔细检查以下配件，如有缺失或者损坏，
请及时联系当地店面或者邮件至厂家（support@fmsmod-
el.com)，告知缺失或损坏的配件名称及编码（请在本说明书
尾页查看相应的配件编码）。
请注意：不同配置，包装盒内部物品不同。
·························································
目录
30
·····························································
30
31
34
···························································
36
36
1. 4258-KV550 电机，捕食者 70A 电调
2. 高扭力空心杯设计的 30G 金属数码舵机
3. 碳纤加强杆
4. 中空设计机翼
5. 金属球头结构舵角（预安装），加大行程
6. 便捷的螺丝组装结构
7. 无需胶水
33
35
35
34
产品特点
产品组成
机体安装
电池安装
接收机连接示意图
遥控器设置
夹头安装方式
舵角和舵机摇臂安装
重心调整
飞行前准备
配件列表
故障检修指导
33
35
·····························································
·····························································
······························································
···················································
···························································
························································
···············································
······························································
·····························································
···············································
特点：
························································
