FMUser SDA-15B - Operation Explanation and Display

Web: www.fmuser.net Email: rita@fmuser.net Skype: rita.cai87 MSN: rita_cai_jxpx@hotmail.com
4 / 11
9
【▲】/【▼】
Adjust
In the parameter setting pages,【▲ 】means
increase,【▼】means decrease
Change
MONO/STEREO change page, 【▲ 】 means
STEREO，【▼】means MONO.
Turn
In the home page, press【▲】or 【▼】 to enter/exit
the home page/second page.
10
【
】
Exit
In the parameter adjusting pages, press this
button to exit that page and turn back to home
page.
Standby
In the home page, press this button for 3 seconds
to standby status.
Alarm
When VSWR/Temperature is in danger and under
proection, press this button to turn to home page.
5.Operation Explanation
1. Character Display Description
No Character Display
Name Description
1
FMxxx.xMHz
Broadcasting
frequency
The current broadcasting frequency is
xxx.xMHz
2
PWR：xx.xW Output power
The current output power is xx.x watt.
3
xx℃
Transmitter
Temerature
The current amplifier tube surface
temperature is xx℃
4
SWRx.x SWR Value
The current SWR value is x.x，（Min.1.0
means no reflection, Maximum value 9.0
means the power are all reflected back.
Smaller value means less power reflection）
5
LOCK Button lock
Means all the buttons has been locked(not
including【LOCK】button）
6
LINE：x x Audio Volume
The Volume of Audio input
7
MIC：x x
Microphone
Volume
The Volume of Microphone Input
8
LINE：*** Audio Mute To mute the Audio input
9
MIC：***
Microphone
Mute
To mute the microphone input
10
MIC：x xE
Microphone
Reverberation
a
E means reverberation ON
