FOAMICO SATELLITE SYSTEM PSU 0127 - Page 14

14 PSU 0127- 7003313-16-19-20 15-04-2019
QTY.
NO:
Description
Description1
Beschreibung
1
1001551
Satellite cabinet welded
Prediluted detergent
Gehäuse
1
1002303**
Block
Prediluted chemicals 2 foam
Block komplett
1
1001887**
Block
Prediluted chemicals foam - des.
Block komplett
1
1002280**
Block
Prediluted chemicals 1 foam
Block komplett
2
1001219
Connection tube for satellite
3 Injector system
Verbindungsrohr für Satelliten
4
1000719
Nut for union
Blok part
Schraube für Verschraubung
4
1000720
Union
Blok part
Verschraubung
3
1000260
Foam Lance
1/2" RG Male - Female
Schaumlanze
1
1001337
Inlet pipe for Satellite
1/2" RG Male - Female
Eingangsrohr für Satellit
2
1000189
Male elbow 90 degrees
1/2" RG
Winkel 90° - 1/2" RG
4
1000718
Union
for block
Verschraubung
2
1000072
Nipple 1/2"
120mm
Nippel 1/2" 120mm
1
1000134
Pressure regulator with
Filter- Manometer. fittings
Druckreduzierventil mit
1
1002127
Pressure regulator with
Filter- Manometer. T - fittings
Druckreduzierventil mit
1
1001556
Front plate satellite
Prediluted detergent
Frontabdeckung
1
1700138
Labels
Set
Symbole
1
1000334
Button Head Screw
ISO 7380 - M6 x 10 - 10N
Schraube
1
1001886*
Block Foam
for prediluted chemicals
Block Schaum
1
1001883*
Block Foam
concentrated chemicals
Block Schaum
4
1000069
Ball valve
1/2" RG female female
Kugelhahn
1
1001234
Air inlet assembly
All models
Lufteinlassanordnung
1
1700074
Connector
Ø8 Hose - 1/4"RG
Gerade Steckkupplung AG
1
1001557
Top bracket satellite
Satellite L=300 mm
Obere Halterung für Satellit
4
1000643
Union strait 1/2"RG
Stainless steel
Verschraubung ½"
1
1001948
Front Label Foamico
Prediluted Satellite
Vorderen Etikett Foamico
Table 8.1 Overview Satellite system
*1001886 for machines (7003312-15-18)
*1001883 for machines (7003311-14-17)
** 1002303 for machines (7003313-14-15-16-17-18)
** 1002280 for machines (7003310-11-12)
