6 PSU 0127- 7003313-16-19-20 15-04-2019
3 Operation
Rinsing
1. ATTENTION! Make always sure that the valve, POS. K, POS. A, POS. E and POS J, fig. 4.1 are closed.
2. Mount the rinsing hose with the coupling in POS. E, fig. 4.1 and make sure the valve is closed.
3. Check the low-pressure valve/gun and make sure it is closed.
4. Mount the rinsing nozzle or rinsing pipe in the coupling at the low-pressure valve/gun (marked with blue
or green protection)
5. Turn the handle POS. D, fig. 4.1 into the position/function “rinsing” .
6. Open the ball valve POS. A, fig. 4.1 and the ball valve POS. E, fig. 4.1
7. The System is now ready for rinsing. Rinse by opening the low-pressure valve/gun
8. ATTENTION! After rinsing, the hose must be depressurized. Close the valve POS. A fig. 4.1 and open the
low pressure valve/gun.
9. Close the Valve POS. E fig. 4.1 after the system has been depressurized. The hose can now be
disconnected.
Foaming chemical 1
1. ATTENTION! Make sure that the valves POS. K, POS. A, POS. E und POS J, fig. 4.1 are closed.
2. Mount the rinsing hose with the coupling POS. E, fig. 4.1
3. Make sure the low-pressure valve/gun at the end of the hose is closed.
4. Mount the foam nozzle (marked with white protection) into the coupling of the low-pressure valve/gun
5. Turn the handle POS. D, fig. 4.1 into the position/function “foaming” .
6. Open the ball valve POS J, and POS. E, fig. 4.1.
7. Adjust the air pressure to 4-6 bar on the regulator pos H fig 4.1 (differs from detergent to detergent. Often
has to be fine-tuned during first time foaming)
8. The system is now ready to foam. Apply foam by opening the low pressure valve/gun.
9. ATTENTION! The air supply is always to be closed while the foaming function is not in use. POS. B, fig,
4.1
10. ATTENTION! After foaming, the hose must be depressurized. Close the valve POS. J fig. 4.1 and open
the low pressure valve/gun.
11. Close the Valve POS. E fig. 4.1 after the system has been depressurized. The hose can now be
disconnected.
Foaming chemical 2
1. ATTENTION! Make sure that the valves POS. K, POS. A, POS. E und POS J, fig. 4.1 are closed.
2. Mount the rinsing hose with the coupling POS. E, fig. 4.1
3. Make sure the low-pressure valve/gun at the end of the hose is closed.
4. Mount the foam nozzle (marked with white protection) into the coupling of the low-pressure valve/gun
5. Turn the handle POS. D Abb. 4.1 into the position/function “foaming” .
6. Open the ball valve POS K, and POS. E, fig. 4.1.
7. Adjust the air pressure to 4-6 bar on the regulator pos H fig 4.1 (differs from detergent to detergent. Often
has to be fine-tuned during first time foaming)
8. The system is now ready to foam. Apply foam by opening the low pressure valve/gun.
9. ATTENTION! The air supply is always to be closed while the foaming function is not in use. POS. B, fig,
4.1
10. ATTENTION! After foaming, the hose must be depressurized. Close the valve POS. K fig. 4.1 and open
the low pressure valve/gun.
12. Close the Valve POS. E fig. 4.1 after the system has been depressurized. The hose can now be
