FOAMICO SATELLITE SYSTEM PSU 0127 User Manual

16 PSU 0127- 7003313-16-19-20 15-04-2019
QTY.
NO:
Description
Description1
Beschreibung
1
1001666
Ball / shaft for
2 injector system
Kugle - Welle für
4
1002337
Ball gasket for
2 Injector system
Kugeldichtung
1
1002279
Block part
2 prediluted chemicals
Hauptteil für
1
1002174
Top plate for block
2 Injector system
Top für block
1
1000533
Bearing for shaft
3 injector system
Lager für Welle
2
1001899
Spring f. position ball
Position disk
Feder f. Positionierung Scheibe
2
1001819
Ball f. Check valve
1/4"- 6,35mm
Kugel f. Rückschlagventil
1
1001002
Check valve
1/4" x 1/4" male - male EPDM
Rückschlagventil Luft
1
1001577
Air valve
Ø6
Luft Ventile
1
1001649
Position plate 2 foam for
2 Injector system
Positionierung Plate für
1
1001683
Bracket for block
2 Injector system
Halter für
1
1000726
Nope for shaft
-
Achse
1
1000727
Handel for
3 Injector block
Griff
1
1000840
Nipple 1/2"
70mm
Nippel 1/2" 70mm
1
1000069
Ball valve
1/2" RG female female
Kugelhahn
1
1000037
Quick connect coupling
1/2"RG male
Schnellverschlusskupplung 1/2" AG
3
1000576
O-Ring
Ø11,0 x 1,78
O-Ring
1
1000534
Pressure ring for
3 Injector system
Druckring für
1
1001681
O-Ring
Ø39,45 x 1,78
O- Ring
4
1001750
Socket Head Cap Screw
EN ISO 4762 M6 x 16
Zylinder Schraube
4
1000495
Washer
DIN 125 -A 6,4
Unterlegscheibe
1
1001816
Bottom part
2 prediluted chemicals
Platte
2
1001787
Chek valve
Detergent
Rückschlagventil
1
1001793
Chek valve
Water
Rückschlagventil
2
1000541
O-seal
Ø4,8 x 1,78
O- Ringe
2
1001205
Button Head Screw
Schraube
1
1001788
Elbow
90 Degrees Ø6 - 1/4" Female
Winkel
2
1001276
Capscrew
ISO 7045 - M4 x 18
Schraube
1
1001196
Socket Head Cap Screw
EN ISO 4762 M5 x 45
Zylinder Schraube
Table 8.2 Spare parts – pipe system – rinsing circuit
