9.0 INSTALLATION - TABLE TOP - CONTINUED
GB IE
© 2015 Focal Point Fires plc.
7. Repeat steps 10 and 11 on the Installation wall mounted to change the log fuel bed to pebble.
8. Repeat steps 12 on the Wall Mount configuration to install the Glass Fascia on the firebox.
10.0 OPERATING THE APPLIANCE
On the top right side plate of the Electric Fireplace is the control panel. This panel
contains the buttons to properly operate the electric fireplace. The buttons on the
control panel on the side of the Electric Fireplace and the Remote Control function in
the same way. The remote control has an effective range of up to 13 feet.
1. Main Power Button
2. Flames Control Button
3. Timer Function Button
4. Side Light Control Button
5. Thermostat On/Off Button
6. Thermostat Control Button
1.
2.
3.5.
4.
6.
