specifications
Diablo Utopia
Type 2-way bass-reex bookshelf speaker.
Drivers 6
1/2
” (16.5cm) “W” Power Flower midbass.
1
1/16
” (27mm) IAL2 pure Beryllium inverted dome tweeter.
Frequency response (±3 dB) 44Hz - 40kHz
Low frequency point (-6 dB) 40Hz
Sensitivity (2.83 V/1 m) 89dB
Nominal impedance 8Ohms
Minimum impedance 4Ohms
Crossover frequency 2 200Hz
Recommended amplier power 25 - 200W
Dimensions (HxWxD) 16
15/16
x10
3/16
x16
13/16
(431x258x427mm)
Net weight 44lbs (20kg)
09
Your Focal-JMlab product was developed and manufactured with high-quality materials and components which can be recycled and/or
reused. This symbol indicates that electrical and electronic equipment must be disposed of separately from normal garbage at the end of its
operational lifetime.Please dispose of this product by bringing it to your local collection point or recycling centre for such equipment. This will
help to protect the environment in which we all live.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Focal DIABLO UTOPIA and is the answer not in the manual?

Focal DIABLO UTOPIA Specifications

General IconGeneral
Frequency Response44Hz - 40kHz
Sensitivity89dB
Nominal Impedance8 Ohms
Typebookshelf speaker
Drivers1" Beryllium inverted dome tweeter, 6.5" W composite sandwich woofer
Crossover Frequency2.5kHz
Dimensions431 x 258 x 427 mm (16.93 x 10.16 x 16.81 in)
Weight20 kg (44 lbs)
