DIMENSION
Schnellstartanleitung
Deutsch
TV TV
OU
TV
*Falls Sie über mehr als eine HDMI-Quelle verfügen, empfehlen wir Ihnen, einen HDMI-Schalter zu verwenden oder den Anschluss über
Ihr Fernsehgerät laufen zu lassen.
**Je nach Land ist ein Subwoofer im Lieferumfang enthalten bzw. optional erhältlich.
1. Lieferumfang
1 x Netzteil
1 x Stromkabel
1 x Dimension Soundbar
1 x Wandhalterung
2 x Standfüße
1 x Fernbedienung
2. Verwendung
Mit Dimension Sub Ohne Dimension Sub An der Wand, alleine oder mit
aktivem Subwoofer
3. Installation
Aufgestellt auf einem Möbelstück
An der Wand befestigt
4. Verkabelung:
Anschlussleiste:
Dimension Sub**
HDMI CEC
zur Audio-Video-Quelle
HDMI ARC / CEC
zum Fernseher
RCA zum Subwoofer
Modell Sub Air oder Cub
3**
Optischer Anschluss:
Fernseher oder AV-Quelle
Mini-Jack: Smartphone
/ Computer / aptx
Bluetooth-Modul
Mini-USB: Dieser Anschluss
wird ausschließlich vom
Focal Kundendienst für
eventuell notwendige
Systemupdates genutzt
Stromversorgung
