Focus ERGOFOCUS User Manual

3
Specifications
• Not for mobile home installation!
• Do not connect to any air distribution duct or system!
• The authority having jurisdiction (such as municipal building department, fire department, fire prevention
bureau, etc.) Should be consulted before installation to determine the need to obtain a permit.
• Using make-shift compromises during installation can cause damage. Such installation is not covered under
focus limited warranty.
• When this room heater is not properly installed, a house fire may result. To reduce the risk of fire, follow the
installation instructions. Contact local building or fire officials about restrictions and installation inspection
requirements in your area.
CHARACTERISTICS
• Hearth 37-3/8-inch (0.95m)
diameter; weight 116 lbs
(53 kg)
• Flue diameter: 8-3/8-inch
(219mm) ;
length custom-made
• Flue weight: 10,6 lbs per foot
(16kg per meter)
• Standard plate weight
of 42 lbs (19 kg)
• 1/8-inch (3 mm) thick steel
• High heat resistant paint
• Stainless steel ball-bearing
revolving system
for a 360° rotation
• Fire screen
ERGOFOCUS
Scale 1 : 20
Note : imperial are rounded from metric
floor
(sol)
8’’ adaptor
27
3
/16"
(690 mm)
67 1/8"
(1.705 mm)
29
1
/8"
(740 mm)
7
7
/
8
"
(199 mm)
Ø 8 1/16" id
(Ø 205 mm)
Ø 8 5/8" od
(Ø 219 mm)
Ø 37 3/8"
(Ø 950 mm)
20"
(500 mm)
40 1/2"
(1040 mm)

Focus ERGOFOCUS Specifications

General

Brand	Focus
Model	ERGOFOCUS
Category	Indoor Fireplace
Language	English
