Physical and Electrical Characteristics
Inputs 1 & 2
Connectors
XLR x 2 (Mic); ¼” TRS jack x 2 (Line); ¼”
TS jack x 1 (Inst) on rear panel
Mic/Line switching Automatic
Line/Instrument switching (Ch 1 only) Automatic
Phantom power
Shared +48 V phantom power switch for
Inputs 1 & 2
Outputs
Monitor outputs 2 x balanced ¼” TRS jacks on rear panel
Stereo headphone output ¼” TRS jack on side panel
Main output level control
On top panel
Headphones level control
Other I/O
USB 1 x USB MIDI 2.0 Type A connector
Top Panel Indicators
Power/data comms Green LED
Phantom power Red LED
Gain controls
Colour-coded LED rings (green = -24 dBFS;
red = 0 dBFS with 1 sec. peak hold)
Weight and Dimensions
W x H x D 280 mm x 64 mm x x168 mm
Weight 0.7 kg
iTrack Studio CM25B microphone specifications
Capsule
Type 20 mm dia. condenser element
Response type Cardioid
Mounting Standard 5/8” female; 3/8” adaptor supplied
Performance
Frequency Response 30 Hz – 20 kHz
Sensitivity -36 dB ±2 dB (0 dB = 1 V/Pa)
Self noise 18 dBA
Maximum SPL 130 dB (1 kHz)
S/N Ratio 76 dB (A-weighted)
Impedance 150 ohms
Power Via 48 V phantom supply
