17
SPECIFICATIONS
Performance Specifications
ADC Dynamic Range
105 dB ‘A-weighted’ (all inputs). Converter chipset
A/D dynamic range 114 dB
DAC Dynamic Range
Range 104 dB ‘A-weighted’ (all outputs). Converter
chipset D/A dynamic range 114 dB
Supported sample rates 44.1 kHz, 48 kHz and 96 kHz
Clock source Internal
Microphone Inputs (Chs 1 & 2)
Frequency Response 20 Hz – 20 kHz +/-0.5 dB (minimum gain)
Gain Range -5 dB to +45 dB
Max input level +4 dBu min.
THD+N
<-94 dB (minimum gain, -1 dBFS input with
20 Hz/22 kHz bandpass filter)
Noise EIN
<-120 dB CCIR-RMS (60 dB gain with 150 ohm
termination)
Line Inputs (Chs 1 & 2)
Frequency Response 20 Hz – 20 kHz +/-0.5 dB (minimum gain)
Gain Range -22 dB to +28 dB
Max input level +21 dBu min. (@ 1% THD+N)
THD+N
<-80 dB (minimum gain, -1 dBFS output with
20 Hz/22 kHz bandpass filter)
Noise (NiPoS)
<-104 dBFS CCIR-RMS (min. gain with 50 ohm
termination)
Instrument Input (Ch 1 only)
Frequency Response 20 Hz – 20 kHz +/-0.5 dB (minimum gain)
Gain Range -17 dB to +33 dB
Max input level +14 dBu min.
THD+N
<-90 dB (minimum gain, -1 dB below max. input level
with 20 Hz/22 kHz bandpass filter)
Noise <-104 dB CCIR-RMS (min. gain)
Monitor Outputs 1 & 2
Frequency Response 20 Hz to 20 kHz +/-0.5 dB
Nominal Output Level (0 dBFS) >+10 dBu, balanced; >+4 dBu unbalanced
THD+N <-98 dB (0 dBFS input, 22 Hz/22 kHz bandpass filter)
