C SERIES USER’S MANUAL
18
Chapter Six General Settings and Operation
6.1 Work Status Descriptions
6.1.1 Online/Offline
When the cutter is switched on, it will reset and set to Online status. Press “ONLINE” to
switch Online/Offline status. When the cutter transmits data to PC, the cutter must be in Online
status. But if you need to change the parameters of the cutter or operate manually, the cutter
shall be in Offline status. The LCD shown as followings:
6.1.2 Carriage Movement
When the cutter is Offline status, press “ ”, the carriage will move left and right.
press“▲
”, the main shaft will move back and for the at the same time the LCD will
show X, Y step value respectively.
Online status
Offline status
Online/Offline
