HCD/HMD/HCF/HMF1000R,
HCD/HMD1000N Ice Machines
Following installation, please forward this manual
to the appropriate operations person.
Operation and Service Manual
Serial Number C20001 to C33984
Order parts online
www.follettice.com
OZ
MADE IN
THE USA
PSIG
MODEL
SERIAL NO
CORPORATION
PART NO
HZ
LOW SIDE
CHARGE
VOLTS
Easton Pennsylvania
Module No.
Stock Module Identification Plate
Service No.
Product
REFRIGERANT
R
C
AMPS
AMPS
DESIGN PRESSURE HIGH SIDE
MIN. BRANCH CIRCUIT AMPACITY
MAX. BRANCH CIRCUIT FUSE SIZE
MOTOR COMPRESSOR THERMALLY PROTECTED
FULL LOAD AMPS
R
SINGLE
PHASE
208264
NSF
U
L L
U
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-5086 • +1 (610) 252-7301
www.follettice.com
01034719R05

Questions and Answers

  • E
    Edward HowardAug 12, 2025
    Why is my Follett C33984 Ice Maker running but not making ice?
    • B
      Brandy GarrisonAug 13, 2025
      Your Follett Ice Maker might be running but not producing ice due to several reasons: * A defective compressor, start relay, start capacitor, or run capacitor may be the cause. Consider replacing these components. * A defective main contactor or PC board could also be the issue, requiring replacement. * The machine might be in a Purge cycle. Check for Purge operation.
  • H
    Hannah GutierrezAug 16, 2025
    What to do if my Follett Ice Maker is not making ice and shows HI AMPS?
    • C
      Christina AllenAug 16, 2025
      If your Follett Ice Maker isn't producing ice and displays a HI AMPS error, consider the following: * Poor water quality might be causing ice to jam the auger. Clean the ice machine and increase flushing frequency. * A damaged shuttle mechanism or thermostat (closed) could be the problem. Replace or repair these components. * A kinked transport tube (in thermostat systems) can cause this. Straighten the transport tube. * Intermittent drive output from the PC board may cause the evaporator to freeze, leading to a hi amps error. Replace the PC board. * Ensure the gearmotor is properly plugged in.
  • S
    Susan JacobsAug 20, 2025
    Why is my Follett Ice Maker not making ice and showing a Lo water error?
    • S
      Sabrina BryantAug 20, 2025
      If your Follett Ice Maker isn't making ice and displays a Lo water error, it could be due to: * The water supply being turned off. Turn the water supply on. If the evaporator was completely empty, you may need to press the reset button to restart the ice machine. * Low water pressure. The ice machine will eventually start when the water reaches the normal low level. * A defective water feed solenoid valve stuck in the closed position. Replace the water feed solenoid valve. * No water feed output from the PC board. Replace the PC board.
  • S
    sanfordlauraAug 23, 2025
    Why is my Follett C33984 in TIME DELAY even though the bin is not full?
    • M
      matthewsmithAug 25, 2025
      If your Follett Ice Maker is in TIME DELAY without a full bin, it could be due to: * Ice jamming caused by an improperly installed transport tube, leading to a false shuttle. Correct the transport tube routing. * The shuttle being stuck in the up position. Repair or replace the shuttle mechanism. * A damaged or improperly installed thermostat (open). Replace or reposition the thermostat. * The transport tube backing out of the coupling. Correct the coupling installation.
  • A
    Andrew AllenAug 28, 2025
    Why is there excessive water in the bin of my Follett C33984 Ice Maker?
    • T
      Troy WatersAug 28, 2025
      Excessive water in the bin of your Follett Ice Maker might be due to: * Failed water sensors, causing the processor to incorrectly detect water levels. Try cleaning or replacing the water probe assembly and checking the wiring connections. * A blocked reservoir vent. Clean or replace the vent tubes. * A defective water feed solenoid valve stuck in the open position. Replace the water feed solenoid valve.
  • E
    Erin CooperAug 31, 2025
    What to do if my Follett C33984 is not making ice due to a drain clog?
    • C
      Christopher ThompsonAug 31, 2025
      If your Follett Ice Maker is not making ice due to a drain clog: * Check for a kinked or plugged drain hose causing water to back up. Remove any kinks or blockages. * Ensure proper fol or drain routing/pitch to prevent water backup. Re-route the fol or drain if necessary. * High TDS levels and a leaking drain solenoid may cause a drain clog. Clean the area around the drain sensor and/or replace the drain solenoid valve.
  • T
    Tina RobertsSep 4, 2025
    What does it mean when my Follett C33984 is locked in PURGE and not making ice?
    • C
      Craig MelendezSep 4, 2025
      If your Follett Ice Maker is locked in PURGE and not making ice, it could be because: * A self-flush occurred but the evaporator could not drain due to a failed drain solenoid valve. Replace the drain solenoid valve. * A self-flush occurred but the evaporator could not drain because the water reservoir or ice machine is not level. Level the ice machine and check the water reservoir to ensure it is not tilted towards the compressor.
  • R
    rodriguezmarioSep 8, 2025
    What to do if the CPU is not flashing on my Follett C33984 Ice Maker?
    • C
      Christian BruceSep 8, 2025
      If the CPU is not flashing on your Follett Ice Maker, the processor may be damaged. Replace the PC board.

Follett C33984 Specifications

General IconGeneral
BrandFollett
ModelC33984
CategoryIce Maker
LanguageEnglish
