4
TECHNICAL MANUAL FOR INSTALLATION, USE AND MAINTENANCE
1 GENERAL INFORMATION
Please read and retain this manual in order to achieve full
satisfaction from the boiler use.
The equipment name, series, model, serial number and
technical data are shown on the label located inside the
boiler.
The letters following the commercial name define the main
features of Your wall-hung boiler according to the scheme
below:
Model:
S E:
heating only, natural draught, open
combustion chamber (B11BS - EN297);
X E:
heating and hot water instantaneous
production, natural draught, open combustion
chamber (B11BS - EN297);
S ER:
heating only, forced draught, sealed
combustion chamber (C2x, C62 - EN483);
X ER:
heating and hot water instantaneous
production, forced draught, sealed
combustion chamber (C62x, C62 - EN483).
All the models have the same following features:
- electric ignition;
- continuous flame modulation with microprocessor;
- nominal heat input 25 kW (21.500 kcal/h).
2 WARNINGS
This manual is delivered with the boiler and should always
be stored in the vicinity of the equipment for proper use
and maintenance.
PRELIMINARY OPERATIONS
Unpack the boiler by removing its cardboard and do not
turn it upside down. Always keep the boiler vertical on its
lower polystyrene base. Never place the boiler direcly on
the floor. After unpacking the boiler, make sure that the
equipment is intact. When in doubt, contact your supplier.
For safety reasons and correct operation, installation must
be carried out by professionally qualified technicians, in
compliance with current regulations and Manufacturer’s
instructions.
Manufacturer abdicates any responsibility in case of
damage caused by tempering, incorrect use and wrong
equipment installation, use and maintenance.
Should failures or malfunctioning occur, turn the equipment
off, refrain from making any repairs and call the Service
Centre.
NOTE!
The boiler
COMMISSIONING
must be carried out
by the
Service Centre technicians within 8 days from the
installation of the equipment. After commissiong, the
Service Centre shall fill in the guarantee certificate and
release part of it, which must be stored, thus starting the
guarantee period. Carefully read the conditions specified
in the guarantee form. Service during the guarantee period
shall be provided if the guarantee slip has been validatd
during commissiong.
NOTE!
Maintenance is compulsory and must be executed
at least once a year (DPR 412/93, 551/99). Contact the
authorised Service Centre. In any case, only technicians
who are qualified according to the laws in force can carry
out the maintenance activities.
3 INSTALLATION
NOTE!
ONLY authorised and professionally-qualified
technicians who know the equipment, have read this
manual and comply with the (national and local) laws in
force in the place of installation, can install the equipment.
3.1 BOILER LOCATION
Open chamber boilers can only be installed in place which
comply with current regulations and, in any case, in
permanently ventilated places. Use the two screws anchors,
supplied with the equipment, to install the boiler on a strong
masonry wall. Leave at least 35 cm from the front panel of
the front panel of the equipment to facilitate use and
maintenance activities; leave at least 40 cm between the
top of the equipment and the ceiling and between the
bottom of the equipment and the floor and from any other
no-removal impediment. When defining the installation
height of the boiler, make sure that this its top part cannot
be easily reached with one’s hands.
NOTE
! Do not install the boiler in a dusty or very humid
environment. If the boiler is installed outdoor, it must be
protected against RAIN, ICE, HUMIDITY and DUST; make
sure that unauthorised people, children, animals, or
anything else which may damage or be damaged by the
boiler, cannot easily access the boiler.
