FOR-A MFR-16 User Manual

86
5-4-4-4. BUTTON ASSIGN
This menu displays the assignment list for PAGE 1.
To Assign Functions to Buttons:
(1) Turn the control knob to select a page.
(2) Press a button for assignment. The button will blink and its information will be
displayed.
(3) Turn the control knob to select a function to the button.
(4) Use the control knob to set the corresponding parameter(s). Once the settings are
complete, the current DEST button blinks and "SAVE" is displayed on the button.
(5) Press the current DEST button to confirm the settings.
To perform another assignment, proceed from Step (1).
FUNC Menu List
FUNC
Parameter
Description
Remarks
NONE
DEST
DESTINATION
Destination channel
LEVEL
Level (Available level number are
displayed.)
SRC
SOURCE
Source channel
LEVEL
Level (Available level number are
displayed.)
BUS
DESTINATION
channel
SOURCE
Source channel
LEVEL
Level (Available level number are
displayed.)
PAGE
TYPE
JUMP: Moves to the set page.
UP: One page forward
DOWN: One page back
FORWARD
Page to jump
When TYPE
is set to
JUMP:
REVERSE
Page to return
HOME: Back to the origin page
GROUP
Page group selection
MODE
TARGET
Mode selection when using the Mode
button
LOCK
TYPE[S]
Lock mode selection for the
short-press of the LOCK button.
DESTINATION[S]
Destination channel setting for the
short-press of destination buttons.
CURRENT: Locks the current
destination
When ALL or
OTHER is
set for
TYPE[S]:
TYPE[L]
Lock mode selection for the
long-press of the LOCK button.
DESTINATION[L]
Destination channel setting for the
long-press of destination buttons.
CURRENT: Locks the current
destination
When ALL or
OTHER is
set for
TYPE[S]:
TAKE
LEVEL
Level (Available level number are
displayed.)
LINK
TENKEY
SKIP
BWD/FWD
Mode selection
COUNT
Number to be skipped
