Force 10 Galley - Built-in Installation

Page 4 of 15
Built-in Installation
Cutout Dimensions:
Width: 25.1” (635 mm)
Depth: 21.75” (553 mm)
Height: 24.5.” (623 mm)
The opening between the cabinets should be 25” (635mm) wide, 21.75” (553mm) deep
and 24.5” (623mm) high. This height leaves clearance for changing the battery.
Attach the trim kit and front spacer to the right and left stove sides as shown in the
diagram below using the enclosed screws. (6) Screws per side.
