Force JX-DS925 - Page 14

Assembly Instructions
Step 9
Attach the left sliding frame(33#) through the rear vertical frame(32#), and attach the rear vertical frame
(32#) to the left stabilizer(23#),Secure them together with 2pcs M10*20 Allen bolt(63#) and 2 pcsφ10
washer(69#).
Move the sliding frame and Select the desired height with the T shape lock pin(47#).
Repeat the same way to install the another one.
13
