Force JX-DS925 - Components - Fixings

Note: The quantities below are the correct amount to complete the assembly. In some cases more
hardware may be supplied than are required. Some of the fixings are pre-fitted to the larger components.
Please check carefully before contacting us regarding any missing fixings.
Components - Fixings
Please check you have all parts listed below
4
6# Allen bolt wrench X1
8# Allen bolt wrench X1
4# Allen bolt wrench X1
5# Allen bolt wrench X1
L=13 bushing X4
L=15 bushing X6
Big washer(Φ25*Φ10.5 )X2
M10*60 Allen bolt X 2
M10*140 Allen bolt X 1
Φ8 washer *8
M10 Aircraft nut *71
φ16X158×M10 swivel axle X 1
φ10 washer X121
φ12 washer X4
φ
16
×
64
×
M10 swivel axle X2
M12 Aircraft nut X2
M8*18 Allen bolt X8
M10*16 Allen bolt X2
M10*20 Allen bolt X16
M10*28 Allen bolt X4
M10*45 Allen bolt *34
M10*65 Allen bolt X5
M10*70 Carriage bolt X17
M12*90 Allen bolt X 2
