A Attach the end of the 3980 mm leg press cable(84#) to the bracket and secure it with 1PC M10X28
Allen bolt (62#),2pcs
φ
10 washer (69#) and 1pcM10 Aircraft nut (68#).
B. Place 1
st
pulley(103#) below the cable and secure the pulley to the bracket as the diagram shows
with 1PC M10X45 Allen bolt (61#),2pcs φ10 washer (69#) and 1pcM10 Aircraft nut (68#).
C. Draw the cable around the pulley and forwards , place 2
st
pulley below the cable,and secure the
pulley with the same way in B.
D.Draw the cable around the pulley and backwards, and place 3
st
pulley below the cable,Secure it with
1PC M10X65 Allen bolt (59#),2pcs bushing (72#) and 1pc M10 Aircraft nut (68#).
E. Draw the cable around the pulley and downwards , place 4
st
pulley onto the cable,Secure it with the
same way in D.
F.Draw the cable backwards and place the 5
st
pulley onto the cable,Secure the pulley with the same
way in B.
G.Draw the cable around the pulley and upwards, place the 6
st
pulley below the cable,secure it with the
same way in B.
H. Draw the cable around the pulley and downwards,place the 7
st
pulley onto the cable, Secure the
pulley with the same way in B.
I Draw the cable around the pulley and upwards,Place the 8
st
pulley below the cable, secure the pulley
with the double floating pulley bracket together with the same way in B.
J Draw the cable around the pulley and downwards.
