A Attach the end of the 4020MM lower cable(85#) to the hook as the diagram shows.
B Draw the cable downwards and place 1pc pulley onto the cable, secure it with double floating pulley
bracket(36#) together with 1PC M10X45 Allen bolt (61#),2pcs φ10 washer (69#) and 1pcM10 Aircraft
nut (68#).
C. Draw the cable around the cable and upwards,place 1 pc pulley below the cable and secure the
pulley with the same way in A.
D.Draw the cable through the hole of short guide rod and vertical frame, Place 1 pc pulley below the
cable and secure it with 1PC M10X60 Allen bolt (60#),2pcs bushing (73#) and 1pcM10 Aircraft nut
(68#).
E,F.Draw the cable around the pulley and downwards,place 2 pcs pulleys onto and below the
cable,Secure them with the same way in A.
