Force JX-DS925 - Accessory and Final Attachment (Steps 21-23)

Assembly Instructions
Step 21
A. Place the seat pad(40#) to the seat pad support （5#） and secure it with 4pcs M8×18 Allen bolt
(65#) and 4pcs
φ
8 washer(70#).
B. Attach the backrest pad(41#) to the front vertical frame（3#）, Secure it with the same way in A.
C.Install the shoulder pad as the diagram shows
29
