Next Generation Firewall Hardware Guide | Models N120W, N120WL,and N120L
If the plug-and-play configuration method is not used, the on-site installer must use the USB drive that
contains the initial configuration files to configure the NGFW Engine software.
3) When you have finished installing the appliance, inform the SMC administrator so that the administrator can
check the status of the appliance in the Management Client.
Insert a SIM card for models N120WL and
N120L
To use the LTE modem in N120WL and N120L models, you must insert a separately-purchased SIM card into the
appliance.
Before you begin
Before you insert or replace a SIM card, turn off the appliance.
The SIM card must be a Nano-SIM card. Full-sized SIM cards, Mini-SIM cards, and Micro-SIM cards are not
supported.
Note
To use the mobile connection for plug-and-play configuration, make sure that the PIN code query is
disabled on the SIM card. For more information, see Knowledge Base article 17249.
Steps
1) To release the SIM card tray, gently push the SIM card tray.
2) Remove the SIM card tray.
3) With the SIM card contacts facing down, insert the SMC card into the tray, then gently push the tray back into
the SIM card slot.
Attach antennas for models N120W, N120WL,
and N120L
Attach the antennas included in the delivery to the appliance.
Before you begin
Before you attach or replace the antennas, you must turn off the appliance.
The following antennas are included with the delivery:
■
Wireless LAN antennas — 3 pieces, round whip antennas
17
