Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
64 40A Heater blower motor
R1 — Ignition relay
R2 — Air pump motor relay
R3 — Cooling fan (Run-on fan) relay
(2.3L engine only)
R4 — Not used
R5 — High beams relay
R6 — Low beams relay
R7 — Fuel pump relay
R8 — Engine management relay
R9 — Cooling fan relay (2.0L engine
only)
R10 — Cooling fan 2 relay (2.0L engine
only)
R11 — Air conditioning relay
R12 — Daytime Running Lamps (DRL)
relay
R13 — Fog lamps relay
R14 — HID lamps (SVT only)
R15 — Cooling fan high speed (A/C only)
relay (2.0L engine only)
R16 — Cooling fan low speed relay
D1 — PCM diode
D2 — Cooling fan diode
D3 — A/C clutch diode
CHANGING A FLAT TIRE
If you get a flat tire while driving:
• do not brake heavily.
• gradually decrease the vehicle’s speed.
• hold the steering wheel firmly.
• slowly move to a safe place on the side of the road.
Roadside Emergencies
134
