Function Number of bulbs
Trade
number
Front park/turn lamp 2 3157NA
*Front sidemarker lamp N/A LED
Headlamp
2 9008 H13
2
D3 HID
(optional)
Tail/brake/turn signal lamp
2 3157K
N/A
*LED
(optional)
Supplemental taillamp 2 194
Rear sidemarker
2 194
N/A
*LED
(optional)
Backup lamp 2 921
License plate lamp 2 C5WL
*High-mount brake lamp N/A LED
Fog lamp (if equipped) 2 H11
Map lamp 2 12V6W
Dome/reading lamps 6 578
To replace all instrument panel lights - see your authorized dealer.
*To replace these lamps - see your authorized dealer.
Replacing interior bulbs
Check the operation of all bulbs frequently.
Replacing headlamp (high beam/low beam) halogen bulbs
1. Make sure headlamp switch is in the off position, then open the hood.
2. Reach in behind the headlamp assembly to access the bulb sockets
and connectors.
Lights
87
2010 Flex (471)
Owners Guide, 1st Printing
USA (fus)
