Grand C-MAX
WARNING
Luggage retention net anchor points
are not fitted behind the first row
seats, but are fitted behind the
second row seats.
Luggage retention net
Installing the net
CAUTIONS
Do not move the rear seats when the
cargo net is installed.
Do not use the cargo net if the third
row seats are in use.
1. Push the ends of the upper bar
towards each other and insert them
into the retainers on the roof. Push the
bar forwards into the narrow section
of the retainers.
Note:
Make sure the centre seat is
upright.
Note:
Only install the cargo net behind
the rear seats.
2. Attach the net to the luggage anchor
points. See Luggage anchor
points (page 163).
3. Tighten the belts.
166
Load carrying
