Circuits protected
Ampere
rating
Fuse
Heated windscreen (left-hand side)4016
Fuel fired heater2017
Windscreen wipers2018
ABS ESP module519
Horn1520
Stop lamp switch521
Battery monitoring system1522
Relay coils, light switch module523
Rear power outlet2024
Electric exterior mirrors1025
Powertrain control module (PCM)1526
Air conditioning clutch1527
Not used-28
Heated rear window2529
Engine control module530
Not used-31
EGR Valve, swirl control valves, HEGO sensor (engine
management)
1032
Ignition Coils1033
Injectors1034
Diesel filter heater, active grille shutters1535
Engine control module1036
ABS537
Engine control module, transmission control module1538
Headlamp control module539
Electric power assisted steering540
Body Control Module2041
178
Fuses
